Dispensing systems for 2K fluids

All our applications are based on volumetric proportioning systems managed by controllers and/or PLCs, this allows the process to be controlled with highest precision and to guarantee reliability.

2K Volumetric Dispensing Systems are made from 2 dispensing systems, feeded by follower plate pumps or by pressurized tanks which come in PCP cavity or gear pumps, chosen in the best size for the dispensed amount, the cycle time, the fluids viscosity.



This pump, drived by an electronic system, allow to have the right proportioning between the 2 components, with an infinite adjusting (also by remote) without any needed setup by the operator.

An auto tuning/calibration system cause the following of the correct mixing ratio, also with different viscosity fluids.



With this systems is possible to dispense drops, beads of make fillings, without any refilling time.

The dispensing systems can be moved manually, with the operator that handle an ergonomic gun with mixer, or can be fixed with the part that is approached by the operator.



Otherwise the systems can be inserted in robotic cells and mounted on robots and so on.



Pressure switch, mixing blocks and mixers complete the systems that are tailor made on the customer needs, and if requested, installed by DAV Tech technician.

Manual systems

  • Various sizes Tanks
  • Fixed dispensing system, with gun or balancer
  • Dispensing through volumetric pumps
  • Quantity dispensed and / or flow rate settable from the operator panel
  • Tanks level control
  • Integrated remote assistance system - Industry 4.0 ready

WATCH VIDEO

Feeding from originals drums

Other options

Pumps in many sizes and types

Resin heating

control

Resin stirring

system

Degassing

systems

Automatic systems

  • Various sizes Tanks
  • Color touch screen HMI

Handling by:

  • 3-axis systems
  • 3-axis gantry systems
  • 6-axis robots/SCARA
  • Cobots
  • Volumetric dispensing with progressive cavity pumps or gear pumps
  • Complete process management by PLC/ Panel PC
  • Process control systems, master cycles, etc...
  • Production traceability systems/MES

WATCH VIDEO

Feeding from originals drums

Other options

Pumps in many sizes and types

Resin heating

control

Resin stirring

system

Degassing

systems

Accessories and devices

Advantages

Many modular pumps sizes to allow the perfect choice for any application

Dispensing not affected by temperature and viscosity changes

Systems

for remote

assistance

Various tank sizes or feeding from original drums

Possibility to dispense filled materials without wearing problems

Potential applications

Potting and encapsulation processes on:

Electronic board cases

LED / OLED lighting devices

Transformers and windings

Sensors and resistors

Thermo-conductive paste dispensing processes for:

Batteries for electric/hybrid mobility

Heatsinks for lighting components

Heatsinks for electronic boards

Structural bonding processes for:

Structural bonding solutions using

pre-filled

cartridges

Production of insulating panels

Bonding steel on glass

Bonding on composite materials
